Azure Key Vault – Azure Saturday satazureday Ottawa

satazureday

I had the opportunity to speak at satazureday Azure Saturday here in Ottawa last week, and went through the topic of Azure Key Vault. I also had a co-presenter to share the talk with; an upcoming public speaker Petrica Mihai. He created most of the slides and the demo code in C# 🙂
You can view the code at https://github.com/mihaipetri/AzureKeyVaultNet

In any case if you are interested here are the slides on Azure Key Vault.

And the transcript:

  1. Azure Key Vault • What are we trying to solve with KeyVault?
  • Let’s step back and look at a Cloud Design Pattern
  • External Configuration Pattern
  • External Configuration Pattern
  • Typical Application
  • Storing Configuration in file
  • Multiple application
  • External Configuration Pattern
    • Helps move configuration information out of the application deployment
    • his pattern can provide for easier management and control of configuration data
    • For sharing configuration data across applications and other application instances
  • Problems
    • Configuration becomes part of deployment
    • Multiple applications share the same configuration
    • Hard to have access control over the configuration
  • External Configuration Pattern
  • When to use the pattern
    • When you have shared configuration, multiple application
    • You want to manage configuration centrally by DevOps
    • Provide audit for each configuration
  • When not to use
    • When you only have a single application there is no need to use this pattern it will make things more complex
  • Cloud Solution Offerings
    • Azure KeyVault (Today’sTalk)
    • Vault by Hashicorp
    • AWS KMS
    • Keywhiz
  • What is Azure Key Vault ?
    • Safe1guard cryptographic keys and secrets used by cloud applications and services
    • Use hardware security modules (HSMs)
    • Simplify and automate tasks for SSL/TLS certificates
  • Gemalto / SafeNet – Hardware Security Module
  • How Azure Key Vault can help you ?
    • Customers can import their own keys into Azure, and manage them
    • Keys are stored in a vault and invoked by URI when needed
    • KeyVault performs cryptographic operations on behalf of the application
    • The application does not see the customers’ keys
    • KeyVault is designed so that Microsoft does not see or extract your keys • Near real-time logging of key usage
  • Bring Your Own Key (BYOK)
  • Create a Key Vault New-AzureRmKeyVault -VaultName ‘MihaiKeyVault’ -ResourceGroupName ‘MihaiResourceGroup’ -Location ‘Canada East’
  • Objects, identifiers, and versioning
    • Objects stored in Azure KeyVault (keys, secrets, certificates) retain versions whenever a new instance of an object is created, and each version has a unique identifier and URL
    • https://{keyvault-name}.vault.azure.net/{object-type}/{object- name}/{object-version}
  • Azure Key Vault keys
    • Cryptographic keys in Azure KeyVault are represented as JSONWeb Key [JWK] objects
    • RSA: A 2048-bit RSA key.This is a “soft” key, which is processed in software by KeyVault but is stored encrypted at rest using a system key that is in an HSM
    • RSA-HSM: An RSA key that is processed in an HSM
    • https://myvault.vault.azure.net/keys/mykey/abcdea84815e4ca8bc19c f8eb943ee88
  • Create a Key Vault key $key = Add-AzureKeyVaultKey -VaultName ‘MihaiKeyVault’ -Name ‘MihaiFirstKey’ -Destination ‘Software’
  • Azure Key Vault secrets
    • Secrets are octet sequences with a maximum size of 25k bytes each
    • The Azure KeyVault service does not provide any semantics for secrets; it accepts the data, encrypts and stores it, returning a secret identifier, “id”, that may be used to retrieve the secret
    • https://myvault.vault.azure.net/secrets/mysecret/abcdea54614e4ca7 ge14cf2eb943ab23
    • Create a Key Vault secret $secret = Set-AzureKeyVaultSecret -VaultName ‘MihaiKeyVault’ -Name ‘SQLPassword’ -SecretValue $secretvalue
    • Azure Key Vault certificates
      • Import/generate existing certificates, self-signed or Enroll from Public Certificate Authority (DigiCert, GlobalSign andWoSign)
      • When a KeyVault certificate is created, an addressable key and secret are also created with the same name
      • https://myvault.vault.azure.net/certificates/mycertificate/abcdea848 15e4ca8bc19cf8eb943bb45
    • Create a Key Vault certificate
    • Secure your Key Vault
      • Access to a key vault is controlled through two separate interfaces: management plane and data plane
      • Authentication establishes the identity of the caller
      • Authorization determines what operations the caller is allowed to perform
      • For authentication both management plane and data plane use Azure Active Directory
      • For authorization, management plane uses role-based access control (RBAC) while data plane uses key vault access policy
    • Access Control
      • Access Control based on Azure AD
      • Access assigned at theVault level
      • – permissions to keys
      • – permissions to secrets
      • Authentication against AzureAD
      • – application ID and key
      • – application ID and certificate
    • Azure Managed Service Identity (MSI)
      • Manage the credentials that need to be in your code for authenticating to cloud services
      • Azure KeyVault provides a way to securely store credentials and other keys and secrets, but your code needs to authenticate to Key Vault to retrieve them
      • Managed Service Identity (MSI) makes solving this problem simpler by giving Azure services an automatically managed identity in Azure Active Directory (Azure AD)
      • You can use this identity to authenticate to any service that supports AzureAD authentication, including KeyVault, without having any credentials in your code

      Azure Key Vault Logging

      • Monitor how and when your key vaults are accessed, and by whom
      • Save information in an Azure storage account that you provide
      • Use standard Azure access control methods to secure your logs by restricting who can access them
      • Delete logs that you no longer want to keep in your storage account
    • Azure Key Vault Pricing • Operations (Standard or Premium) $0.030 per 10000 operations
      • Advanced Operations (Standard or Premium) $0.150 per 10000 operations
      • Certificate Renewals (Standard or Premium) $3.00 per renewal
      • Hardware Security Module Protected Keys (Premium only) $1.00 per key
    • Azure Key Vault DEMO
      • Create KeyVault, Secrets, Keys and Certificates
      • Create AzureAD Application
      • Consuming Secrets and Keys https://azurekeyvaultnet.azurewebsites.net – live demo
      • https://github.com/mihaipetri/AzureKeyVaultNet – demo code
